U500.TB0.2-ZZZZ.72F Ultrasonic through beam sensors (11200636)

•
•

U500.TB0.2-ZZZZ.72F Ultrasonic through beam sensors (11200636)

U500.TB0.2-ZZZZ.72F Ultrasonic through beam sensors (11200636)

U500.TB0.2-ZZZZ.72F Ultrasonic through beam sensors (11200636)

SKU: BAU.11200636

HAN: 11200636

HAN: 11200636

Category: Robust ultrasonic sensors with parameterization flexibility

Low stock level

175,41 €

incl. 19% VAT ,

Manufacturers:

Baumer

Ultrasonic through beam sensors

emitter
0… 2000 mm
connector M12 5 pin
-25 … 65 °C
IP 67

no description available

Technical data

General data
Emitter / receiver	Emitter
Scanning range Sd	0 … 2000 mm
Scanning range far limit Sde	0 … 2000 mm
Sonic frequency	200 kHz
Power on indication	LED green
Electrical data
Voltage supply range +Vs	12 … 30 VDC
Current consumption typ.	25 mA
Residual ripple	< 10 % Vs
Short circuit protection	Yes
Reverse polarity protection	Yes, Vs to GND
Mechanical data
Design	Rectangular
Housing material	Plastic (ASA, PMMA)
Coating active face	PEEK
Width / diameter	18 mm
Height / length	45 mm
Depth	32 mm
Connection types	Connector M12 5 pin
Ambient conditions
Operating temperature	-25 … +65 °C
Storage temperature	-40 … +75 °C
Protection class	IP 67

Item information	Value
Power on indication:	LED green
Emitter / receiver:	Emitter
Scanning range Sd:	0 … 2000 mm
Scanning range far limit Sde:	0 … 2000 mm
Sonic frequency:	200 kHz
